INRS Researchers Design the World’s Fastest UV Camera

Write by Audrey-Maude Vézina

October 7, 2020

( update : October 15, 2020 )

L’équipe du professeur Jinyang Liang, spécialiste en imagerie ultrarapide à l’Institut national de la recherche scientifique (INRS), en collaboration avec une équipe internationale de chercheurs, a mis au point une caméra, la plus rapide au monde, capable d’imager des photons dans l’ultraviolet (UV) en temps réel.

This original research is featured on the front cover of the 10th issue of the journal Laser & Photonics Reviews. Imagine being able to snap a picture of extremely fast events on the order of a picosecond (11 zeros after the decimal point!). Compressed ultrafast photography (CUP) captures the entire process in real time and unparalleled resolution with just one click. The spatial and temporal information is first compressed into an image and then, using a reconstruction algorithm, it is converted into a video.


Developing a Compact Instrument for UV

Des chercheurs de l’INRS conçoivent la caméra UV la plus rapide au monde
Artistic impression of single-shot UV-CUP which made the front cover of the 10th issue of the journal Laser & Photonics Reviews.
Picture : Wiley-VCH GmbH

Until now, this technique was limited to visible and near-infrared wavelengths, and thus to a specific category of physical events. “Many phenomena that occur on very short time scales also take place on a very small spatial scale. To see them, you need to sense shorter wavelengths. Doing this in the UV or even X-ray ranges is a remarkable step toward this goal,” says Jinyang Liang, who led the study.

To record in this new range of wavelengths and to develop the technique into a user-friendly product, researchers designed a compact UV-CUP system with Christian‐Yves Côté of Axis Photonique Inc. via an academia-industry collaboration. The new system features a patterned photocathode, which is used to simultaneously detect and encode “black light”. “Like a standard camera, our technology is passive. It does not produce light; it receives it. Therefore, our photocathode had to be sensitive to the photons emitted as UV light. This design makes our technique a stand-alone system that can be easily integrated into various experimental platforms,” says Jinyang Liang, who has been contributing to the development of CUP since his postdoctorate.

Liang worked with François Légaré, also an INRS professor, to generate and take images of UV pulses at the Advanced Laser Light Source (ALLS) laboratory.

“The outstanding research environment at the Énergie Matériaux Télécommunications Research Centre of INRS is very helpful. It is so much more efficient when all necessary design, manufacturing, and characterization capabilities are available in the same building.”

Jinyang Liang


Dividing up the Reconstruction Problem reconstruction

Des chercheurs de l’INRS conçoivent la caméra UV la plus rapide au monde
Compact, one-box UV-CUP system.
Photo : Jinyang Liang

“Taking the picture is only the first half of the job,” says Jinyang Liang. “It also has to be reconstructed.” To do this, the researchers developed a new algorithm, more efficient than standard algorithms, via their collaboration with Boston University. Its strength comes from a division of tasks. “Rather than solve the reconstruction problem as a lump, the algorithm divides the reconstruction into smaller problems that it tackles individually. It’s like trying to eat a cake. Instead of finishing it in one mouthful, you enjoy it much more one small bite at a time,” explains Professor Liang.

With the innovations in both hardware and software, UV-CUP has an imaging speed of 0.5 trillion frames per second. It produces videos with 1500 frames in large format. As a light-speed imager, UV-CUP sees flying UV photons in real time.

“It always fascinates me when you can watch the fastest object in the universe in such great detail.”

Yingming Lai, a Master’s student at INRS and the first author of the article

Even though it is the fastest camera in the world, the device can still be improved. For example, the chosen photocathodes have limited efficiency, so researchers want to explore other types of materials. Regarding reconstruction, Jinyang Liang says that the algorithm has greatly improved the quality, but that it still takes quite a long time. To increase its speed, he is collaborating with Professor Tiago Falk, also from INRS, on using artificial intelligence to improve it.

The device developed through this international collaboration will be sent to the research laboratory SOLEIL Synchrotron in France to visualize physical phenomena. It could capture laser-plasma generation, a phenomenon that is essential for deducing certain properties of materials, and UV fluorescence, which is important in medical imaging to identify biomarkers linked to diseases.
